Large Area UV LED Curing Machine for Offset Printing

Large Area UV LED Curing Machine for Offset Printing

The UV LED curing light  is designed for high speed offset printing with a large irradiation area of 325x40mm. This system offers a peak irradiance of 16W/cm2 at 395nm, ensuring fast and uniform curing even at at maximum production speeds.

Additionally, it features replaceable outer windows, making it easier to maintain in printing applications. Experience fast and uniform curing with the convenience of maintenance in printing applications with advanced UV curing system.


The fan-cooling UVSN-780J5-M is high power UV lamp delivering an irradiance of over 16W/cm2, which means that the curing process is accelerated, resulting in faster production speeds and increased output. Whether in the printing industry or other applications that require efficient curing, this UV LED light source is the perfect solution.

The UV curing system features an large curing area of 325x40mm, ensuring excellent uniformity throughout the entire curing area, even at at maximum production speeds. This means that it can achieve consistent high-quality results on large printing surfaces or any other applications that require a wide curing area. The precision and accuracy of this UV curing system set it apart from traditional arc lamp solutions, guaranteeing exceptional performance and reliability.

Furthermore, UVSN-780J5-M has an extraordinary lifespan of up to 20,000 hours. This means reduced operational costs compared to arc lamp solutions, making it a cost-effective choice for businesses. Additionally, the system offers replaceable outer windows, making maintenance easier, especially in printing applications.

In conclusion, the UVSN-780J5-M is a UV LED curing device that combines high intensity and large area curing capabilities with exceptional uniformity. Its advanced features, such as replaceable outer window and long lifetime, ensure ease of maintenance and superior performance. With reduced running costs compared to arc lamp solutions, the UVSN-780J5-M offers a cost-effective and reliable solution for various UV curing needs.

  • Specifications
  • Model No. UVSS-780J5-M UVSE-780J5-M UVSN-780J5-M UVSZ-780J5-M
    UV Wavelength 365nm 385nm 395nm 405nm
    Peak UV Intensity 12W/cm2 16W/cm2
    Irradiation Area 325X40mm
    Cooling System Fan Cooling

    Looking for additional technical specifications? Contact with our technical experts.
